TaaS (Testing as a service)
- Performance and Production testing of Products - WiFi, Bluetooth, Zigbee, 6LoWPAN, WiFi-ah, RFID
- Power output measurement
- Sensitivity measurement
- Impedance matching
- Antenna tuning
- Measurement of Spurious emission in different bands
- Design corrections and Rework.
- Test plan definition and Test procedures execution for Production testing.
- Complete in-house lab facilities with High Precision test equipment.
Keysight Oscillscope
- Oscilloscope with different ranges.
- Bode Plot to characterize the power supply designs
- Function generators
Vector Network Analyzer
- Dual Port VNA in Sub 6 GHz range
- S11,S12,S21,S22 measurements
- Embedding and De-Embedding features
- TDR measurements
Keysight DMM
- 6.5 Digits which can measure as low as pA
- Histogram details for problem analysis
- Automation for production Testing
Power Supplies
- Programmable power supplies in different ranges
- Steps, Ramps and Linear increments
- Emulates distortion with scripts
- Automated Production testing
Tektronix Logic Analyzer
- Deep memory and High speed timing analysis of digital logic signals
- 500 ps timing resolution
- Captures elusive hardware problems
- Programmable scripts to automate analysis
Signal Generator
- WiFi, Bluetooth, Zigbee, etc Signal generation for receiver sensitivity analysis
- Different patterns and sweep emulations.
Spectrum Analyzer
- EMC Compliance tests
- WiFi, Bluetooth, Zigbee, etc wireless signal characterization
- WiFi and Bluetooth signals Interference and Emission measurements
Design & Simulation
- Simulation study and analysis of RF passive circuits and Antennas with OpenSource Tools.
Vertical Anechoic Chamber (Under Maintenance)
Vertical Anechoic Chamber (Under Maintenance)
- Attenuation 100db @ 20MHz to 6GHz
